E-Lites Sharp Eye 19*15W Led Moving Head Light

Spectacular Countless Vortex Effects.

The Sharp Eye is the Ace product of E-Lites factory.is high performance wash light, a mid-air beam light ,a creative visual effect light.This is a perfect LED based moving head that is packed with a diverse feature set at an affordable price.

The Sharp Eye 19*15W is a effective wash light which has the ability to reach wide range of color wash area .Thanks to the installation of special BEE EYE optial lens system,the Sharp Eye is more powerful that other LED wash moving head at same power .

With a smoothly zoom system  from 4° to 60°,the Sharp Eye can be a wash light also a beam light. It will become a mid-air parallel beam light when the beam angle zoomed to the minimum angle. The Sharp eye can also be a spectacular Graphic Effect light, since each LEDs  be controlled individually. Whatsmore, The front lens system is infinite rotating for countless vortex effects .

Features :

Light source :Osram RGBW Leds

Led Type :19pcs of 15Watt Leds

Function :Wash, Beam,FX effects

Lens :Special Bee Eye rotating front lens system

Control of Led :All the parameters of each LED can be completely controlled

Beam angle :4°- 60°

White balance:2500-8000K

Display : LCD or Touch screen

In order to maintain this condition and to ensure a safe operation, Here are safety instructions and warning notes for reference :

1. In order to guarantee the product’s life, please don’t put it in the damp places or even the environment over 60degress.

2.Always mount this unit in safe and stable matter. If the device has been exposed to temperature changes due to environmental changes, do not switch it on immediately. The arising condensation could damage the device. Leave the device switched off until it has reached room temperatures. This device falls under protection-classⅠ. Therefore it is essential that the device be earthed. The electric connection must carry out by qualified person.

Make sure the power cord is never crimped or damaged by sharp edges. If this would be the case, replacement of the cable must be done by an authorized dealer.

3.CLEANING AND MAINTENANCE

1) To reduce the risk of electrical shock or fire, do not expose this unit to rain or moisture.

2) Do not spill water or other liquids into or on to your unit.

3)During long periods of non-use, disconnect the unit’s main power.

4)It should be installed in a well-ventilated place, at a distance of 50 centimeters or more with the walls. At the same time, please check if the fan and ventilation holes are unobstructed.

4.Inspection

1) All screws for installing the devices or parts of the device have to be tightly connected and

must not be corroded.

2) There must not be any deformations on the housing. Fixations and installations spots(ceiling,

suspension, trussing).

3) Mechanically moved parts must not show any traces of wearing and must not rotate with

unbalances.

4) The electric power supply cables must not show any damage, material fatigue or sediments.

Further instructions depending on the installation spot and usage have to be adhered by a

skilled installer and any safety problems have to be removed.
