470W Beam Moving Head Light

ELB-BEAM470W-21R

BEAM 470 , installed 1pc of  Japanese Panasonic bulb 21R  lamp and 2°high resolution and precise optics delivers high brightness beam effect.Its straight, sharp 2˚ beam makes it a cost-saving investment for a wide range of applications. Digital position correction technology offers fast and smooth movement. A wide range of mid-air effects is achievable via static gobo wheel(13 gobos) and color wheel (14 colors) in conjunction with two rotating 8+8+8 honeycomb prism, 16 -facet prisms. The impressive 356,000 lux@5m output helps the unit to deliver the utmost in terms of light quality and number of effects.



Key points:

  • high power Japanese Panasonic bulb21R
  • 2°tight beam lens
  • Fast and smooth movement,16bit pan/tilt fine
  • Excellent color mixing effect and rainbow effect
  • 14 colors HQ color wheel installed which make colorful beam effect
  • 7 fixed images + 5 white light of different sizes + white light
  • 8+8+8 honeycomb prism, 16 prism (double prism can be superimposed by 40, and can be rotated independently in both directions)
  • High efficiency, low power consumption, long lifetime
  • Low noise and efficient FAN cooling system
  • Scan position memory, auto reposition after unexpected movement
  • Built-in programs with macro effects
  • Linear electronic focus
  • Linear electronic frost
  • Indoor operation temperature:-20°C~+40°C
  • DMX512, master-slave and sound activated controllable or auto operation
  • Auto-switching power supply that can accommodate a widerange of input voltages

LIGHT SOURCE
Lamp :Japanese Panasonic bulb 470w

Ballast of lamp :electronic ballast

Life Span: 2000Hrs

Color Temperature: 7800K

OPTICAL SYSTEM

Lens :High precision Lens

Beam Angle:2°

POWER

Power Supply: AC 90-260V, 50/60Hz
Power Consumption: 650W

PHOTOMETRIC DATA

Lumen: 57470 lux@2m

COLOR SYSTEM

Color Wheel : 14 colors + open with Split Colors and Rainbow effect

GOBO SYSTEM

Gobo wheel:  7 fixed + 5 white light of different sizes + white light

Atomization: 1 independent atomization effect, soft and natural light spot

PRISM SYSTEM

Prism 1 : 8+8+8 honeycomb prism, 16 prism (double prism can be superimposed by 40, and can be rotated independently in both directions)

CONTROL
Control Mode: DMX512, master-slave, sound activated or auto operation,

DMX Channels:16CH

PHYSICAL
Display: LCD Menu Display+4 buttons

Protect Rate: IP20

Housing : Moulded fire proof ABS PC +aluminum and steel metal plates

Color :Black or White

Pan :540°

Pan resolution :16bit

Tilt :270°

Tilt :resolution :16bit

PAN/TILT reversible and scan position memory, auto reposition after unexpected movement.

Dimmer: 0-100%

Strobe: Variable strobe effect

Cooling :Efficient low noise self adjusting fan cooling system

Focus: motorized focus

Frost: electronic frost

DATA

Power :PowerCon connection in & out

DMX : 3pin or 5pin in & out

WEIGHT & DIMENSION
Weight: 21 kg

Accessories

Flightcase of 2pcs Beam Moving Head :

Gross Weight: 68kg

Power Cable

Signal Cable

PowerCon Jump cable

Safety Cable

Hanging Clamp

Hanging Omega

Specification

LIGHT SOURCE
Lamp :Japanese Panasonic bulb 470w

Ballast of lamp :electronic ballast

Life Span: 2000Hrs

Color Temperature: 7800K

OPTICAL SYSTEM

Lens :High precision Lens

Beam Angle:2°

POWER

Power Supply: AC 90-260V, 50/60Hz
Power Consumption: 650W

PHOTOMETRIC DATA

Lumen: 57470 lux@2m

COLOR SYSTEM

Color Wheel : 14 colors + open with Split Colors and Rainbow effect

GOBO SYSTEM

Gobo wheel:  7 fixed + 5 white light of different sizes + white light

Atomization: 1 independent atomization effect, soft and natural light spot

PRISM SYSTEM

Prism 1 : 8+8+8 honeycomb prism, 16 prism (double prism can be superimposed by 40, and can be rotated independently in both directions)

CONTROL
Control Mode: DMX512, master-slave, sound activated or auto operation,

DMX Channels:16CH

PHYSICAL
Display: LCD Menu Display+4 buttons

Protect Rate: IP20

Housing : Moulded fire proof ABS PC +aluminum and steel metal plates

Color :Black or White

Pan :540°

Pan resolution :16bit

Tilt :270°

Tilt :resolution :16bit

PAN/TILT reversible and scan position memory, auto reposition after unexpected movement.

Dimmer: 0-100%

Strobe: Variable strobe effect

Cooling :Efficient low noise self adjusting fan cooling system

Focus: motorized focus

Frost: electronic frost

DATA

Power :PowerCon connection in & out

DMX : 3pin or 5pin in & out

WEIGHT & DIMENSION
Weight: 21 kg

Accessories

Flightcase of 2pcs Beam Moving Head :

Gross Weight: 68kg

Power Cable

Signal Cable

PowerCon Jump cable

Safety Cable

Hanging Clamp

Hanging Omega
