BEAM 420 IP65, is a super beam light for outdoor.High power 420W lamp (Philips)，high hardness heat dissipation aluminum profile + flame retardant aging resistant high temperature engineering PVC, adopting outdoor imported fine sand spraying process, anti-UV treatment, anti-aging, high temperature resistance, long service life，makes the BEAM 420 IP65 can be widely used for all kinds of outdoor events.
Imported multi-layer full-coated lens combination, the diameter of the light hole can reach 200mm. The chip controls the fan speed, the original cooling air path structure, with the heat-dissipating shell, can guarantee long-term outdoor use.
Key points:
high power 420W lamp
IP65 protection rate which can be used for outdoor events
1.8°tight beam lens
Fast and smooth movement ,16bit pan/tilt fine
Excellent color mixing effect and rainbow effect
DMX channel mode:16/20CH
13 colors +open+colorful rainbow effect
Independently strobe with double motors, 0.5-20 F.P.S, speed adjustable
Pre-programmed strobe ,pulse strobe、oblique ascension strobe、oblique fall strobe、random strobe、strobe break effect
Built-in programs with macro effects
Linear electronic focus
Linear electronic frost
Over temperature protection management (output decreased when over heat)
DMX512, with RDM function, you can use a large DMX512 controller to remotely set the address code
Auto-switching power supply that can accommodate a wide range of input voltages
Specification :
LIGHT SOURCE
Lamp : 420 (Philips)
Ballast of lamp :electronic ballast
Life Span: 2000Hrs
Color Temperature: 6500K-8500
OPTICAL SYSTEM
Lens :High precision Lens
Beam Angle:1.8°
POWER
Power Supply: AC 90-260V, 50/60Hz
Power Consumption: 650W
PHOTOMETRIC DATA
Lumen: 78123 lux@2m
COLOR SYSTEM
Color palette: 14+rainbow effect+atomization function
GOBO SYSTEM
Gobo wheel: 13 gobos+White
PRISM SYSTEM
8+16 prism, dual prism rotation, adjustable speed.
CONTROL
Control Mode: RDM, DMX512,Auto-running ,Master/salve,Sound active, Built-in program
Channels:16CH
PHYSICAL
Display: LCD full-color liquid crystal display
Protect Rate: IP65
Housing Color :Black
Housing Material: high hardness heat dissipation aluminum profile + flame retardant aging resistant high temperature engineering PVC, adopting outdoor imported fine sand spraying process, anti-UV treatment, anti-aging, high temperature resistance, long service life
Pan :540°
Pan resolution :16bit
Tilt :270°
Tilt :resolution :16bit
PAN/TILT reversible and scan position memory, auto reposition after unexpected movement.
Dimmer: 0-100%
Strobe: Dual-motor independent stroboscopic effect, 0.5-20 times/sec, adjustable speed
Focus: motorized focus
Frost: electronic frost
Shell:fully die cast aluminum.
Lamp body size 695 * 398 * 326 mm
Net weight, 27KG
DATA
Power :Waterproof connection in & out
DMX : 3pin or 5pin in & out
