BEAM 470 IP65, is a super beam light for outdoor.High power SIRIUS HRI Osram lamp，high hardness heat dissipation aluminum profile + flame retardant aging resistant high temperature engineering PVC, adopting outdoor imported fine sand spraying process, anti-UV treatment, anti-aging, high temperature resistance, long service life，makes the BEAM 470W IP65 can be widely used for all kinds of outdoor events.
Imported multi-layer full-coated lens combination, the diameter of the light hole can reach 200mm. The chip controls the fan speed, the original cooling air path structure, with the heat-dissipating shell, can guarantee long-term outdoor use.
Key points:
- high power 350/380/440/470W
- IP65 protection rate which can be used for outdoor events
- 1.8°tight beam lens
- Fast and smooth movement ,16bit pan/tilt fine
- Excellent color mixing effect and rainbow effect
- DMX channel mode:16CH
- 13 colors +open+colorful rainbow effect
- Independently strobe with double motors, 0.5-20 F.P.S, speed adjustable
- Pre-programmed strobe ,pulse strobe、oblique ascension strobe、oblique fall strobe、random strobe、strobe break effect
- Built-in programs with macro effects
- Linear electronic focus
- Linear electronic frost
- Over temperature protection management (output decreased when over heat)
- DMX512, with RDM function, you can use a large DMX512 controller to remotely set the address code
- Auto-switching power supply that can accommodate a wide range of input voltages
Specification :
LIGHT SOURCE
Lamp : high power 470W
Ballast of lamp :electronic ballast
Life Span: 2000Hrs
Color Temperature: 6500K-8500
OPTICAL SYSTEM
Lens :High precision Lens
Beam Angle:1.8°
POWER
Power Supply: AC 90-260V, 50/60Hz
Power Consumption: 800W
PHOTOMETRIC DATA
Lumen: 78123 lux@2m
COLOR SYSTEM
Color Wheel : 13 colors +open+colorful rainbow effect
GOBO SYSTEM
Gobo wheel: 13 gobos+White
PRISM SYSTEM
Prism : one rotated 16 prism and one 8+16+24 facet prism, single prism and double prism superposition can be rotated, (prism can be configured according to customer requirements)
CONTROL
Control Mode: RDM, DMX512,Auto-running ,Master/salve,Sound active, Built-in program
Channels:16CH
PHYSICAL
Display: LCD full-color liquid crystal display
Protect Rate: IP65
Housing Color :Black
Housing Material: high hardness heat dissipation aluminum profile + flame retardant aging resistant high temperature engineering PVC, adopting outdoor imported fine sand spraying process, anti-UV treatment, anti-aging, high temperature resistance, long service life
Pan :540°
Pan resolution :16bit
Tilt :270°
Tilt :resolution :16bit
PAN/TILT reversible and scan position memory, auto reposition after unexpected movement.
Dimmer: 0-100%
Strobe: Dual-motor independent stroboscopic effect, 0.5-20 times/sec, adjustable speed
Focus: motorized focus
Frost: electronic frost
DATA
Power :Waterproof connection in & out
DMX : 3pin or 5pin in & out
