Specification :
LIGHT SOURCE
LED type: 27x40W RGBW
Uniform RGBW color mixing system
Manually adjustable white balance
LED single row control can create a more dazzling chasing effect
LED refresh rate: 800Hz/1200Hz/2000Hz/3600Hz/6000Hz/2000Hz/25KHz optional
OPTICAL SYSTEM
Lens: 43mm high brightness PMMA lens
Beam angle: 4-35°
Zoom system :three-phase motors
POWER
AC100-240V 50/60HZ
Power: 1000W
CONTROL
Control Mode: DMX512, wireless DMX, master-slave
2.4G wireless DMX
DMX Channels:4/5/7/13/16/28 CH
DMX functions: dimming, strobe, RGBW, macro color, color jump, color gradient, rainbow, self-propelled program selection, self-propelled speed, dimming curve selection, and function settings
Software update :Update via DMX link
PHYSICAL
2.4-inch TFT color display screen
Key lock can be set to prevent accidental operation
4 dimming curves: linear, square, inverse square, S-curve
Settings and Addressing: RDM
LED temperature detection system to protect the lifespan of lamp beads
Fan cooling (fan speed changes with temperature)
Fan mode: automatic, silent, and high-speed mode switching
Housing: Die cast aluminum
Dimming curves: linear, square, inverse square, S-curve
IP class IP65
PHOTOMETRIC DATA
97500 LUX@2m, 29600LUX@2m, 13200LUX@6M
DATA
Power connection: Waterproof power socket Seetronic powerCON IN (SAC3MPX)
DMX: waterproof DMX XLR 3-pin Seetronic J3F2C-W
WEIGHT & DIMENSION
Net weight: 20.5KG
Gross weight: 23KG
