Specification:
LIGHT SOURCE
LED: 600W LED Module
Life Span: 20,000 Hours
OPTICAL SYSTEM
Lens: Combined Optical Lens
Zoom Angle: 4° – 35°
Focus System: Linear adjustment from 4 meters to 50 meters
Frost System: 1 independent frost
POWER
Input Voltage: AC 90-240V, 50/60Hz
Rated Power: 750W
COLOR SYSTEM
Colors: 8 colors + white light
Color Mixing System: Linear CMY + CTO color mixing system
GOBO SYSTEM
Fixed Gobo Wheel: 8 fixed gobos + white light + dynamic flame effect
Rotating Gobo Wheel: 7 rotating glass gobos + white light, each pattern can rotate independently forward or reverse
PRISM SYSTEM
Prism System: One 8-facet prism + one 6-row prism, each prism can rotate independently forward or reverse
EFFECTS SYSTEM
Strobe: High-speed strobe, 0-30 times per second with adjustable speed
Dimming: 0-100% linear dimming
CONTROL
Control Mode: DMX512, automatic run, master/slave mode, sound active
DMX Channels: 23/25 channels
Control Signal: International standard DMX512 with RDM function
Software: Supports online upgrades
PHYSICAL
Display: 2.8-inch touch screen + button operation
Operating System: Chinese/English
Pan: 540° with 16-bit electronic error correction
Tilt: 270° with 16-bit electronic error correction
Protection Level: IP20
Cooling Method: Axial fan enhanced cooling
Operating Environment: -20°C to 40°C
Product Color: Black
Housing Material: Metal housing
DATA CONNECTIONS
Power: PowerCon input/output
DMX: 3-pin XLR input/output
WEIGHT & DIMENSION
Net Weight: 22 kg
Dimension: 350 x 260 x 660 mm
