This is a brand new item which equipped with High Color Rendering 700W LED Engines.support every performance at CRI RA≥95 & R9≥90 with no compromise, a complex but compact functional area is waiting. Fixed gobos, rotating gobos, saturated colors, animation disk, framing shutters, linear CMY & CTO, all functions can be layered to create original and complex effects while maintaining a high luminous flux – at a tight angle of 5 °,This is not only a 4-in-1 hybrid moving head, but also an energy-saving and environmentally friendly partner, which ideal for large stages, theatres, dance halls, etc.
Key points:
- Fits a powerful 700W LED engine and its front lens is 180mm diameter Color Temperature: 7,000K
- high CRI mode lumen output up to 31,000 lm
- High CRI mode Ra>95,
- Linear CMY color mixing
- Excellent color macro effect
- Variable CTO: 2700K-7000K
- Static gobo wheel: 1 static gobo wheel with 12 gobos
- Rotating gobo wheel: 1 rotating gobo wheel with 7 gobos, convenient replacment
- Color wheel: 1 color wheel with 6 colors
- Animation wheel: 1 animation wheel with outstanding water and flame effect, the effect disk can rotate and be replaced
- Prisms: 1pc 3-facet prism with rotation in either direction
- Beam Angle: 5°-55°
- Frost: 35°-65°
- Motorized linear Iris 4 x fast and smooth framing shutters;
- The position and the angle of each shutter blade can be controlled individually; Each shutter blade can block out light completely;
- The framing module can rotate at ±60 degrees
- Flicker free management
- Dust-proof and oil-proof design
Specification :
LIGHT SOURCE
LED : 700W White LED engine
Life Span: 10000Hrs
Color temperature: 7000K
OPTICAL SYSTEM
Lens :High precision Lens
Beam Angle:5-55°
POWER
Power Supply: AC 90-250V, 50/60Hz
Power Consumption: 800W
PHOTOMETRIC DATA
Lumen:15000 lx@1m
COLOR SYSTEM
Color Wheel : one color wheel, 6 colors+ Open
GOBO SYSTEM
One static gobo wheel: 12 gobos + open
One rotating gobo wheel: 7 gobos + open, interchangeable, indexable
One animation wheel: dynamic effect like flame or water, etc.
PRISM SYSTEM
Prism :3 facet prism
CMY SYSTEM
Independent CMY, with linear color change, limitless color mixing
CTO SYSTEM
Independent CTO, color temperature can be linear adjusted
CONTROL
Control Mode: DMX512, RDM, master-slave, sound activated or auto operation,
DMX Channels:36CHS
PHYSICAL
Display: LCD Menu Display+5 buttons
Protect Rate: IP20
Housing : Flame-retardant thermoplastic
Color :Black
Pan :540°
Pan resolution :16bit
Tilt :270°
Tilt :resolution :16bit
PAN/TILT reversible and scan position memory, auto reposition after unexpected movement.
Dimmer: 0-100%
Iris: 5%-100% motorized linear iris adjustment
Strobe: Variable strobe effect
Focus: 35°-65° With frost effect, with 3 frost lever-heavy, medium and light
Frost: electronic frost
DATA
Power :PowerCon connection in & out
DMX : 3pin or 5pin in & out
WEIGHT & DIMENSION
N.W.: 36 kgs
G.W.: 38 kgs
Packing size: 90.5x56x45.5CM
