This is a brand new item which equipped with High Color Rendering 700W LED Engines, its size is smaller than ELF-700W-CMY, support every performance at CRI RA≥95 & R9≥90 with no compromise, a complex but compact functional area is waiting. Fixed gobos, rotating gobos, saturated colors, framing shutters, linear CMY & CTO, all functions can be layered to create original and complex effects while maintaining a high luminous flux – at a tight angle of 5 °,This is not only a 4-in-1 hybrid moving head, but also an energy-saving and environmentally friendly partner, which ideal for large stages, theatres, dance halls, etc.Key points:
- Fits a powerful 700W LED engine and its front lens is 180mm diameter Color Temperature: 7,000K
- High CRI mode lumen output up to 31,000 lm
- High CRI mode Ra>95,
- Linear CMY color mixing
- Excellent color macro effect
- Variable CTO: 2700K-7000K
- Static gobo wheel: 1 static gobo wheel with 6 gobos
- Rotating gobo wheel: 1 rotating gobo wheel with 7 gobos, convenient replacment
- Color wheel: 1 color wheel with 7 colors
- Prisms: 1pc 3-facet prism with rotation in either direction
- Beam Angle: 5°-55°
- Frost: 35°-65°
- Motorized linear Iris 4 x fast and smooth framing shutters;
- The position and the angle of each shutter blade can be controlled individually; Each shutter blade can block out light completely;
- The framing module can rotate at ±60 degrees
- Flicker free management
- Dust-proof and oil-proof design
Specification :LIGHT SOURCE
LED : 700W White LED engineLife Span: 10000HrsColor temperature: 7000K
OPTICAL SYSTEMLens :High precision LensBeam Angle:5-55°
POWERPower Supply: AC 90-250V, 50/60Hz
Power Consumption: 800W
PHOTOMETRIC DATALumen:15000 lx@1m
COLOR SYSTEMColor Wheel : one color wheel, 7 colors+ Open
GOBO SYSTEMOne static gobo wheel: 6 gobos + openOne rotating gobo wheel: 7 gobos + open, interchangeable, indexable
PRISM SYSTEMPrism :3 facet prism
CMY SYSTEMIndependent CMY, with linear color change, limitless color mixing
CTO SYSTEMIndependent CTO, color temperature can be linear adjusted
CONTROL
Control Mode: DMX512, RDM, master-slave, sound activated or auto operation,DMX Channels:34CHS
PHYSICAL
Display: LCD Menu Display+4 buttonsProtect Rate: IP20Housing : Flame-retardant thermoplasticColor :BlackPan :540°Pan resolution :16bitTilt :270°Tilt :resolution :16bitPAN/TILT reversible and scan position memory, auto reposition after unexpected movement.Dimmer: 0-100%Iris: 5%-100% motorized linear iris adjustmentStrobe: Variable strobe effectFocus: 35°-65° With frost effect, with 3 frost lever-heavy, medium and lightFrost: electronic frost
DATAPower :PowerCon connection in & outDMX : 3pin or 5pin in & out
WEIGHT & DIMENSION
N.W.: 26 kgsG.W.: 28 kgsPacking size: 65x46x62CM
