LED BAR ZOOM 12*40 ,powered by 12pcs 40Watts Led chips, unique appearance design, the new high-efficiency optical system, the unique optical system offers a large zoom range, from a tight 3° beam to a wide 40° wash. The zoom system can be controlled by two zones, and Each LEDs can be individually control. 3°tight beam angle to output high brightness light array, 40° wide-angle zoom gives excellent wash effect. 4-in-1 RGBW LED sources to create an endless range of color variations, with kinds of macro effects. With smooth Tilt movement 0-230°rotation, allows users to create a luminaire set and control each light in each direction. It provides different kinds of variable speed shutter/strobe effect, virtual color macro effect. available for vertical and horizontal plug-in, make installations fast and easy. It is nice choice for entertainment, renting, TV stations, school halls, weddings, bars, indeed any event.
Key points:
- 12PCS *40Watts RGBW 4IN1 LED
- Each LEDs can be single controlled
- Zoom range 3-40°
- Two independent zoom zones
- 0-230°/16bitTilt moving angle, Fast and smooth movement.
- RGBW color mixing system,excellent color mixing effect and rainbow effect
- 0-100% linear dimmer
- Extremely quiet different working state
- High efficiency, low power consumption, long lifetime
- Pixel color chasing effect
- Pre-programmed random strobe and pulse effects
- Built-in programs with macro effects
- DMX512, master-slave and sound activated controllable or auto operation
Specification :
LIGHT SOURCE
LED : 12 pieces 40W RGBW 4in1 LED
LED brand :TIANXIN
Life Span: 50000Hrs
OPTICAL SYSTEM
3-40° Zoom range
Two independent zoom zone
POWER
Power Supply: AC 90-260V, 50/60Hz
Power Consumption: 560W
PHOTOMETRIC DATA
Lumen: 17200 lux@2m
CONTROL
Control Mode: DMX512, master-slave, sound activated or auto operation
DMX Channels:21/52/62/16CHs
Multi preset internal programs
PHYSICAL
Display: LCD Menu Display+4 buttons
Protect Rate: IP20
Housing : Flame-retardant thermoplastic
Color :Black
Tilt : 0-230° rotation
Tilt :resolution :16bit
Dimmer: 0-100%
Strobe: 0~20HZ
DATA
Power :PowerCon connection in & out
DMX : 3pin or 5pin in & out
WEIGHT & DIMENSION
Weight: 15 kg
Dimension:1020*100*300mm
