The LOGO PROJECTOR 500 IP is a high-intensity 500W LED logo projector designed for outdoor advertising, architectural lighting, and stage effects. With IP65 waterproofing, rugged construction, and customizable gobo patterns, it delivers crisp, vibrant projections even in harsh environments.
Key Features:
- Ultra-Bright 500W LED: 10,000K cool white light for high-contrast, long-range projection.
- 8 interchangeable logo slots (custom designs supported).
- Rotating pattern disk with adjustable speed for dynamic effects.
- Optional round or mosaic square spot shapes.
- Precision Zoom: Adjustable beam angle (4°–60°) for versatile coverage.
- IP65 Protection: Fully dustproof and waterproof for outdoor durability.
- DMX512 (8CH), manual, master-slave, and auto modes.
- LCD menu display for easy configuration.
- Linear 0–100% dimming.
- Robust Build:
- Die-cast aluminum housing + conductive air cooling.
- Waterproof power/DMX connectors (3/5-pin in/out).
Specification :
LIGHT SOURCE
LED : 500 Watts led
Life Span: 80000hrs
OPTICAL SYSTEM
Zoom Angle :4-60° of Lens is available
POWER
Power Supply: AC 90-260V, 50/60Hz
Power Consumption: 550W
PHOTOMETRIC DATA
81500 LUX@1m, 12400LUX@3m
ROTATION GOBOS
Spot shape: round/Mosaic square
Effect pattern: 1 pattern disk (8 LOGO pieces) and variable speed rotation effect
CONTROL
Control Mode: DMX512, master-slave, sound activated or auto operation
DMX Channels:8CH
PHYSICAL
Display: LCD Menu Display+4 buttons
Protect Rate: IP65
Housing :Cast aluminum
Color :Black
DATA
Power : IP65 PowerCon connection in & out
DMX : waterproof 5pin or 3pin DMX in/out
WEIGHT & DIMENSION
Weight: 14kg
Dimension:41*26*24cm
